Dell PowerEdge T160 – E2414,16G, 2TB, 300W)
- Processor: Intel Xeon E-2414 2.6G, 4C/4T, 12M Cache, Turbo, HT (55W)
- Memory: 16GB UDIMM, 5600MT/s DDR5 ECC
- Hard Drive: Dell 2TB Hard Drive SATA 6Gbps 7.2K RPM 512n 3.5in
- Raid Controller: PERC S160 Embedded SATA/SSDs RAID (RAID 0,1,5,10)
- Management: iDRAC9, Basic 16G
- Optical drive: DVD-ROM, SATA, Internal
- Network Controller: Broadcom 5720 Dual Port 1Gb On-Board LOM
- Storage: Up to 3 x 3.5-inch cable SAS/SATA HDD/SSD
- Power Supply: 1x 300W
- Form Factor: Tower
- No OS/ 3 Yrs Pro
- Thông tin sản phẩm
Giới thiệu chung về máy Chủ Dell T160
Dell PowerEdge T160 là một máy chủ tower thế hệ mới, được thiết kế để đáp ứng nhu cầu tính toán mạnh mẽ trong một không gian tối ưu. Đây là lựa chọn lý tưởng cho các doanh nghiệp vừa và nhỏ (SMB) cũng như các ứng dụng Near-Edge, mang đến sự cân bằng giữa hiệu suất, bảo mật và khả năng mở rộng.
T160 không chỉ là một máy chủ mạnh mẽ mà còn là một giải pháp toàn diện, giúp công việc vận hành trơn tru và mở rộng linh hoạt theo nhu cầu phát triển. Mang đến nhiều giá trị cao, đồng hành cùng doanh nghiệp trên con đường chinh phục đỉnh cao, đến với thanh công nhanh hơn nữa.
THÔNG SỐ KỸ THUẬT
|
Feature |
Technical Specifications |
|
|
Processor |
One Intel® Xeon® 6300 series or one Intel® Xeon® E-2400 series processor with up to 8 cores or One Intel® Pentium® G7400/ G7400T processor with up to 2 cores |
|
|
Memory |
• 4 DDR5 DIMM slots, supports UDIMM up to 32 GB per DIMM, speeds up to 4400 MT/s • Supports unregistered ECC DDR5 DIMMs only |
|
|
Storage controllers |
• Internal: HBA355i Adapter, PERC H355 Adapter, PERC H755 Adapter • Internal Boot: Internal USB 3.0, or Boot Optimized Storage Subsystem (BOSS-N1) HWRAID 2 x M.2 SSDs • External HBA (non-RAID): HBA355e Adpt • Software RAID: S160 |
|
|
Drive Bays |
Front bays: • Up to 3 x 3.5-inch cable SAS/SATA HDD/SSD, max 48 TB • Up to 3 x 3.5-inch + 2 x 2.5-inch cable SAS/SATA HDD/SSD, max 63.36 TB |
|
|
Power Supplies |
• 300 W Bronze 100—240 V AC, cabled • 500 W Platinum 100—240 V AC, cabled |
|
|
Cooling Options |
Air cooling |
|
|
Fans |
• One Standard (STD) fan and one optional High performance (HPR) fan • Up to two cabled fans |
|
|
Dimensions |
• Height – 332.5 mm (13.09 inches) • Width – 132.52 mm (5.21 inches) • Depth – 408.8 mm (16.09 inches) (with bezel) |
|
|
Form Factor |
3U tower server |
|
|
Embedded Management |
• iDRAC9 • iDRAC Direct • iDRAC RESTful API with Redfish • iDRAC Service Manual |
|
|
Bezel |
Filter bezel |
|
|
OpenManage Software |
• OpenManage Enterprise • OpenManage Power Manager plugin • OpenManage Service plugin • OpenManage Update Manager plugin |
• CloudIQ for PowerEdge plugin • OpenManage Enterprise Integration for VMware vCenter • OpenManage Integration for Microsoft System Center • OpenManage Integration with Windows Admin Center |
|
Mobility |
OpenManage Mobile |
|
|
OpenManage Integrations |
• BMC Truesight • Microsoft System Center • OpenManage Integration with ServiceNow • Red Hat Ansible Modules • Terraform Providers • VMware vCenter and vRealize Operations Manager |
|
|
Security |
• Cryptographically signed firmware • Data at Rest Encryption (SEDs with local or external key mgmt) • Secure Boot • Secured Component Verification (Hardware integrity check) • Secure Erase • Secured-core server • Silicon Root of Trust • System Lockdown (requires iDRAC9 Enterprise or Datacenter) • TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ |
|
|
Embedded NIC |
2 x 1 GbE LOM |
|
|
GPU Options |
N/A |
|
|
Ports |
Front Ports • 1 x iDRAC Direct (Micro-AB USB) port • 1 x USB 3.2 Gen1 |
Rear Ports • 3 x USB 2.0 • 3 x USB 3.2 Gen1 • 1 x Dedicated iDRAC Ethernet port • 1 x Serial • 1 x VGA • 2 x Ethernet ports |
|
Internal Ports • 1 x USB 3.2 Gen1 |
||
|
PCIe |
Up to two PCIe slots • Slot 1: 1 x8 slot with x4 bandwidth, Half Height, Half Length • Slot 2: 1 x16 slot with x16 bandwidth, Half Height, Half Length |
|
|
Operating System and Hypervisors |
• Canonical Ubuntu Server LTS • Microsoft Windows Server with Hyper-V • Red Hat Enterprise Linux • SUSE Linux Enterprise Server • VMware ESXi For specifications and interoperability details, see Dell.com/OSsupport. |
|
|
OEM-ready version available |
From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you. For more information, visit Dell.com -> Solutions -> OEM Solutions |
|
|
Sustainability feature |
T160 is partially made from recycled steel. T160 exterior metal is made from plated steel without any chemical paint*. NOTE: * Plated steel has a different appearance than regular painted steel. |
|
